GrundfosSKU: 1133424

Grundfos 98420224 Comfort 10-16 TA BU/LC Circulator Pump

$395.92
In stock (35)

The Grundfos 98420224 (Comfort 10-16 TA BU/LC) is an energy-efficient domestic hot water recirculating pump for single and two-family homes with a dedicated return line. Compatible with all water heater types — storage tank, tankless, solar, and heat pump — regardless of whether the system includes mixing or tempering valves. The EcoBrass pump housing is drinking-water approved and lead-free. Rated at 6W maximum power draw, 115–230 VAC, 60 Hz. Includes isolating and non-return valves, built-in temperature sensor, and 6 ft. line cord. Connects via 1-1/4 in. NPSM union fitting.

Please make sure you are ordering the correct UP10-16 pump. Plumbing Planet carries only one version.

Three control modes: AUTOADAPT (learns and adapts to household hot water usage patterns), temperature control (maintains water temperature within an automatically detected range), and continuous operation. New installations require a 3/4" union set or 1/2" union set (sold separately). Professional installation required.

Shipping policy

Orders placed by 2:00pm EST will ship same day, except on holidays.

More Details

Product overview
  • Compatible with all water heater types — storage tank, tankless, solar, and heat pump; works with or without mixing/tempering valves
  • Three control modes: AUTOADAPT (adapts to household usage patterns), temperature control (auto-detected range), and continuous operation
  • Includes isolating and non-return valves, built-in temperature sensor, and 6 ft. line cord
  • 1-1/4 in. NPSM union connection; 110mm port-to-port length
  • Flow rate: 2.2 gpm; maximum head: 3.9 ft.
  • Maximum power: 6W; 115–230 VAC, 60 Hz, 1-phase
  • Maximum operating pressure: 145 psi; fluid temperature range: 35.6–203°F
  • EcoBrass pump housing — drinking-water approved, lead-free
  • Compact design; liquid-lubricated bearing; quiet operation
  • For homes with a dedicated hot water return line — for systems without a return line, see the Grundfos ALPHA Comfort System
Specifications
Manufacturer Part Number 98420224
UPC 5711494712892
Overall Dimensions n/a
Material n/a
Domestic or Import n/a
End Style n/a
Type n/a
ADA Compliance n/a
Warning Professional Installation Required
Standards and Approvals CSA Certified | UL Listed
