Jomar ValveSKU: 1122055

Jomar Valve® 810-504G 3-Way Hot/Cold Ball Valve With Handle, 3/4 in

$109.19
In stock (32)

The Jomar Valve® 810-504G is a 3/4-inch, 3-way hot/cold ball valve made of brass. This tankless water heater isolation valve kit features a 3-way ball valve design and includes a 3/4" relief valve set to 150 PSI, compatible with Navien and AO Smith tankless models. It offers a 600 WOG leakproof stem backed by a lifetime warranty.

Shipping policy

Orders placed by 2:00pm EST will ship same day, except on holidays.

More Details

Product overview
  • Unique TEA coated 3-way style ball
  • (2) PTFE O-Rings with PTFE packing and packing nut guarantees no stem leak
  • US patent no: 7762280 B2
  • 3/4 in 200000 Btu/hr Lead free brass pressure relief valve included
  • 100% leak tested
  • Leak-proof stem lifetime warranty
  • Wetted surface contains less than 0.25 % lead content
  • CW510L Lead free brass end connection/ball/stem, steel - Geomet® plated handle
  • 150 psi working steam pressure
  • PTFE packing, FKM/PTFE stem O-ring, EPDM union washer and Buna-N flat washer
Specifications
Manufacturer Part Number 810-504G
UPC n/a
Overall Dimensions n/a
Material n/a
Domestic or Import n/a
End Style n/a
Type 3-Way
ADA Compliance n/a
Warning n/a
Standards and Approvals ANSI B1.20.7/B1.20.1 | NSF 61-8/372 | NSF 61 - Annex G
